FLYING CLOUD

21 Different Floor Plans to Suit Your Needs

The Flying Cloud line has been one of the most popular Airstream travel trailers for decades, and with good reason. These practical, efficient trailers are designed to move effortlessly from place to place, keeping you cushioned in comfort with advanced storage solutions and an abundance of floor plans that work beautifully for families, long-term travelers, or weekend wanderers. Count on the Airstream Flying Cloud to last far longer than its boxy competitors, all while enjoying less of an impact at the pump and better stability on the road. Inside, there’s a place for everything and everything is in its place, from streamlined cabinetry to sleek fabrics and clever fixtures.

Choose your floor plan, choose your style, and then choose your destination.

Floor Plans

Image Gallery

Specifications

Flying Cloud Specifications

Model specifications

19CB 19CBB 20FB 23CB 23CBB 23FB 25RB 25FB 26RB 27FB 28RB 30RB 30FBB
Exterior Length 19 ft. 2 in. 19 ft. 2 in. 20 ft. 10 in. 23 ft. 23 ft. 23 ft. 9 in. 25 ft. 11 in. 25 ft. 11 in. 26 ft. 11 in. 28 ft. 27 ft. 11 in. 30 ft. 11 in. 30 ft. 10 in.
Exterior Width 8 ft. 8 ft. 8 ft. 8 ft. 8 ft. 8 ft. 8 ft. 5.5 in. 8 ft. 5.5 in. 8 ft. 5.5 in. 8 ft. 5.5 in. 8 ft. 5.5 in. 8 ft. 5.5 in. 8 ft. 5.5 in.
Interior Width 7 ft. 7 in. 7 ft. 7 in. 7 ft. 7 in. 7 ft. 7 in. 7 ft. 7 in. 7 ft. 7 in. 8 ft. 1 in. 8 ft. 1 in. 8 ft. 1 in. 8 ft. 1 in. 8 ft. 1 in. 8 ft. 1 in. 8 ft. 1 in.
Exterior Height with A/C 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in. 9 ft. 9 in.
Interior Height with A/C 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in. 6 ft. 7.5 in.
Hitch Weight (with LP & Batteries) 550 550 631 654 654 467 835 837 903 791 899 899 903
Unit Base Weight (with LP & Batteries) 3,852 3,912 4,271 4,761 4,821 4,806 5,600 5,503 5,973 5,868 5,979 6,517 6,557
Maximum Trailer Capacity (GVWR) (lbs.) 4,500 4,500 5,000 6,000 6,000 6,000 7,300 7,300 7,600 7,600 7,600 8,800 8,800
Net Carrying Capacity (lbs.) 648 588 729 1,239 1,179 1,194 1,700 1,797 1,627 1,732 1,621 2,283 2,243
Fresh Water Tank (gal.) 23 23 23 39 39 39 39 39 39 39 39 54 54
Gray Water Tank (gal.) 21 21 21 21 21 30 35 37 39 37 37 38 39
Black Water Tank (gal.) 18 18 18 18 18 18 37 39 37 39 35 38 37
30 AMP Service Single A/C with Heat Pump (BTU) 13,500 13,500 13,500 13,500 13,500 13,500 15,000 15,000 15,000 15,000 15,000 15,000 15,000
50 AMP Service Dual A/C with Heat Pump (13,500 BTU) OPT OPT OPT OPT OPT STD STD
Ducted Furnace (BTU) 16,000 16,000 18,000 25,000 25,000 18,000 25,000 25,000 25,000 25,000 30,000 30,000 30,000
Refrigerator 2-way

4 cu. ft.

2-way

4 cu. ft.

2-way

4 cu. ft.

2-way

5 cu. ft.

2-way

5 cu. ft.

2-way

5 cu. ft.

2-way

7 cu. ft.

2-way

7 cu. ft.

2-way

7 cu. ft.

2-way

7 cu. ft.

2-way

7 cu. ft.

2-way

8 cu. ft.

2-way

8 cu. ft.

Interior Windows & Skylights 11 11 11 16 16 12 17 17 22 18 19 21 19
Oven (LP Gas) STD STD STD STD STD STD STD STD STD STD STD STD STD
Microwave (*Removed with Convection Option Selected) STD* STD* STD* STD* STD* STD* STD* STD*
Convection Microwave Oven (*Replaces Oven) OPT* OPT* OPT* OPT OPT OPT OPT OPT* OPT* OPT* OPT* OPT* OPT*
Sleeping Capacity (*With Optional Bunk) Up to 5* Up to 4 Up to 7* Up to 4 Up to 6 Up to 6 Up to 4 Up to 6 Up to 6 Up to 6 Up to 8*

Exterior

2 Deep Cycle Group 24 Batteries with Multi-Stage Converter STD
4 Manual Heavy Duty Stabilizer Jacks STD
Airstream Custom Aluminum Step (19’: Thule® Aluminum Step) STD
Aluminum Entry Door Handle STD
Aluminum LP Cover STD
Black Tank Flush System STD
Cable TV Hookup STD
Cast Aluminum Door Hinges STD
Cast Aluminum LED Taillights STD
City Water Inlet with Water Pressure Regulator STD
Custom Handcrafted 26” Wide Entry Door with Window STD
Dedicated Waste Hose Storage STD
Enclosed Aluminum Insulated Heated Underbelly STD
Exterior LP Quick Connect Service Port STD
Exterior Shower with Hot & Cold Water STD
Fluorocarbon Treated UV Protected Aluminum Exterior STD
Goodyear® ST225/75R15 Tires, Balanced STD
Hand Crafted Welded Extruded Aluminum Window Frames STD
Hand Painted Chassis STD
LED Dimmable Patio Awning Light STD
LED Entrance Light STD
LED Tank Service Light STD
LED Storage Compartment Light STD
License Plate Bracket with LED Light STD
Manual ZipDee® Patio Awning with Sunbrella Fabric STD
Nev-R-Adjust® Brakes STD
Nev-R-Lube® Bearings STD
Polished Bumper with Storage STD
Powered Hitch Jack with Light STD
Rear View Camera Pre-wire STD
Satellite TV Hookup STD
Semi-Monocoque Aluminum Superstructure STD
Shock Absorber STD
Solar Pre-wire (Rooftop & Front Access Points) STD
Spare Tire – Full Size STD
Stainless Steel Front Stone Guard Protection STD
Stylized Aluminum Wheels STD
Temperature Reducing One Piece White Aluminum Roof STD
Tempered Tinted Windows with Double Cam Latching System STD
Thermal Barrier Protection Between Interior and Exterior STD
Torsion Axle Suspension STD
Unique Front Door Key with Heavy Duty Deadbolt STD
160w Solar Package with Interior Monitor and AGM Batteries (25’-30’) OPT
80w Solar Package with Interior Monitor and AGM Battery (23’) OPT
Rear View Monitoring System OPT
ZipDee® Rear & Roadside Window Awning with Sunbrella Fabric OPT

Interior

1000W Pure Sine Inverter STD
5/8” WBP Tongue-and-Groove Wood Floor STD
Anti-wicking Outside Edge Floor Sealant STD
Coat & Key Hooks STD
Complete Aluminum Interior Walls and Ceiling STD
EcoBattTM Insulation STD
Electric/LP Water Heater (6 gal.; 9 gal. production) STD
Fantastic© Fan with Thermostat & Automatic Rain Sensor STD
Handcrafted Aluminum Screen Door with Guards STD
Handcrafted Italian Lite-Ply® Laminated Interior Cabinetry STD
LED Interior Lighting with Dimmer STD
Overhead Roof Lockers with Heavy Duty Hinges STD
Panoramic Front Windows with Blackout Shades STD
Probeless Tank Monitoring System STD
QuietstreamTM A/C with Heat Pump & Electronic Thermostat STD
Seamless Vinyl Flooring STD

Galley, Dinette, & lounge

3 Burner Cooktop (LP Gas) STD
Baraldi Cooking Vent with Light STD
Blu-Ray™ DVD Player STD
Clarion Stereo: FM/AM/CD Radio with Bluetooth® (in/out) STD
Samsung LED HD TV with Omni Directional Antenna STD
Dinette Converts to a Lounge and Sleeping Accommodations STD
Flatware Organizer STD
Laminate Dinette Top STD
Laminate Galley Top STD
Oceanair Roller Blinds STD
Pull out Lounge for Sleeping Accommodations STD
Stainless Steel Sink with Cutting Board Sink Cover STD
Surround Sound with Subwoofer STD
Ultraleather® Dwell Lounge and Dinette Seating STD

Bedroom

Blackout Curtain(s) STD
Choice of Either Queen or Twin Beds in 25’ and Larger Models STD
Decorative Throw Pillows STD
Pillow Top Memory Foam Mattress STD
Quilted Bedspread with Duvet STD
Reading LED Lights STD
Samsung LED HD TV (Shared with Galley or Additional Bedroom TV) STD
Sleeping Pillows STD
Under Bed Storage STD
Wardrobe with Hanging Bar STD

Bathroom

Lavy Sink STD
Moen® Bathroom Faucet** STD
Porcelain Toilet STD
Removable Hand Held Shower Head with Shutoff STD
Roof Vent/Fan STD
Towel Bar/Ring STD

Additional Features

2 Year 24/7 Coach-Net® Roadside Assistance STD
2 Year Airstream Limited Warranty (Transferable) STD
Airstream Logo Entrance Mat STD
Emergency Manual Crank for Powered Hitch Jack STD
Fire Extinguisher STD
LP, Smoke & Carbon Monoxide Detectors STD
TRA Certified Green: Emerald Status (Highest Rating) STD
Winterization Bypass Valve STD
THE LISTED ITEMS ARE STANDARD ON THIS MODEL AT NO EXTRA CHARGE UNLESS REPLACED BY OPTIONAL EQUIPMENT.
Specifications are subject to change without notification.
